PEL InverterOn ATOM 1.5 Ton Inverter AC (Heat & cool)

Specifications

• Cooling Capacity: 18,000 BTU
• Rated Cooling Capacity: 5280W (1300–5860W)
• Rated Heating Capacity: 5420W (1300–6300W)
• Rated Running Current (Cooling): 7.8A
• Rated Running Current (Heating): 7.1A

• Rated Input Power (Cooling): 1645W (420–2500W)

• Rated Input Power (Heating): 1500W (420–2500W)

• Voltage Range: 187–265V

• Power Supply: 220–240V~/50Hz/1P

• Compressor Type: Rotary

• Refrigerant: R32 Gas

• Expansion Device Material: Copper

• Noise Levels

• Indoor Unit Noise Level: 44/41/36/30/28 dB(A)

• Outdoor Unit Noise Level: 54 dB(A)

• Indoor Unit Specifications

• Net Weight: 10 kg

• Dimensions (W × D × H): 910 × 294 × 206 mm

• Package Dimensions (W × D × H): 979 × 372 × 277 mm

• Outdoor Unit Specifications

• Net Weight: 24.5 kg

• Dimensions (W × D × H): 795 × 305 × 549 mm

• Package Dimensions (W × D × H): 835 × 340 × 585 mm

PEL InverterOn ATOM 1.5 Ton Inverter AC (H&C) is designed to provide cooling and heating for year-round indoor comfort. With an 18,000 BTU capacity and inverter technology, this air conditioner offers adjustable operating performance to help maintain a comfortable room temperature. Its heating and cooling functionality makes it a practical option for households looking for a single appliance for different seasons.

Powerful Cooling and Heating Performance

The PEL InverterOn ATOM features a rated cooling capacity of 5,280 watts, with an operating range of 1,300 to 5,860 watts. Its rated heating capacity is 5,420 watts, adjustable between 1,300 and 6,300 watts. This flexibility allows the system to adapt its output to changing indoor temperature requirements.

Whether you need refreshing cooling during hot summer days or warmth during colder weather, this heat-and-cool air conditioner is designed to support comfortable indoor living.

Inverter Technology for Flexible Operation

Inverter technology adjusts compressor operation according to cooling or heating demand. The PEL InverterOn ATOM uses a rotary compressor and supports a voltage range of 187–265 V. Its rated power input is 1,645 watts for cooling and 1,500 watts for heating, with input varying according to operating conditions.

Actual electricity consumption depends on room size, outdoor temperature, usage duration, insulation, and the selected temperature. For the best results, choose an appropriate temperature setting and keep doors and windows closed while operating the AC.

R32 Refrigerant and Copper Expansion Device

This model uses R32 refrigerant and features a copper expansion device. R32 is commonly used in modern air-conditioning systems and has a lower global warming potential than R410A. Following the manufacturer's installation and maintenance guidelines helps support reliable system operation.

Noise Levels and Compact Design

The indoor unit offers multiple listed noise levels ranging from 28 to 44 dB(A), while the outdoor unit has a listed noise level of 54 dB(A). The indoor unit measures 910 × 294 × 206 mm and weighs 10 kg. The outdoor unit measures 795 × 305 × 549 mm and weighs 24.5 kg.

These dimensions help you plan the available wall space and outdoor installation area before purchasing.

PEL InverterOn Atom 1.5 Ton Inverter AC on Installments

Buying the PEL InverterOn ATOM 1.5 Ton Inverter AC on installments makes it easier to manage your budget while upgrading your home comfort. Instead of paying the full price upfront, eligible customers can spread the cost over a selected payment period, subject to the retailer's financing options.

Benefits of Buying on Installments

• Affordable Payments: Spread the purchase cost across manageable monthly installments.
• Budget Flexibility: Keep more money available for other household expenses.
• Year-Round Comfort: Enjoy both cooling in summer and heating in winter.
• Convenient Financing: Choose from available installment durations and payment options.
• Better Budget Planning: Review monthly payments in advance to plan your expenses.

FAQs

1. What is the capacity of the PEL InverterOn Atom AC?

PEL InverterOn ATOM has a 1.5-ton capacity, equivalent to 18,000 BTU, making it a potential option for medium-sized rooms depending on their cooling requirements.

2. Does the PEL InverterOn Atom support both heating and cooling?

Yes, this model features heating and cooling functionality, allowing you to maintain a comfortable indoor temperature during summer and winter.

3. What is the cooling capacity of this AC?

Its rated cooling capacity is 5,280 watts, with an operating range of 1,300 to 5,860 watts.

4. What is the heating capacity of the PEL InverterOn Atom?

The rated heating capacity is 5,420 watts, with an operating range of 1,300 to 6,300 watts.

5. Does this AC use inverter technology?

Yes, inverter technology adjusts compressor operation according to cooling or heating demand, helping maintain a more consistent indoor temperature.

6. Which refrigerant does the PEL InverterOn Atom use?

This model uses R32 refrigerant, which has a lower global warming potential than R410A.

7. What is the voltage range of this air conditioner?

The specified voltage range is 187–265 volts, making it suitable for operation within that range.

8. How much electricity does the PEL InverterOn ATOM consume?

Its rated power input is 1,645 watts during cooling and 1,500 watts during heating. Actual electricity consumption varies with usage, temperature settings, and operating conditions.

9. Is the PEL InverterOn Atom suitable for bedrooms?

It may be suitable for appropriately sized bedrooms. The indoor noise level is listed between 28 and 44 dB(A), depending on the operating setting.

10. Can I buy the PEL InverterOn Atom 1.5 Ton AC on installments?

Installment options may be available through selected retailers or financing providers, subject to eligibility and payment terms. Contact Lahore Centre to confirm current plans.

11. Does this AC come with a warranty?

Warranty coverage depends on the manufacturer's terms and the specific purchase. Confirm the compressor, parts, and service warranty before buying.
